Ocean Signal PLB3 (AIS+RLS)

Maksa kolmes võrdses osas: 3 x 220.00 € (ESTO)

660.00 €

The Ocean Signal PLB3 personal locator beacon combines 406 MHz, 121.5 MHz and AIS distress messaging in one PLB. By combining the individual technologies for making emergency calls, the chances of a quick rescue are significantly increased. Using the wireless NFC connection, you can access activity history, battery status programming information of the PLB3 using an app.

SKU: 945631

Kirjeldus

With the introduction of Automatic Identification System (AIS) functionality, Return Link Service (RLS) technology, and Near Field Communication (NFC) capabilities in one 406 MHz Personal Locator Beacon (PLB), the rescueME PLB3 represents a significant step forward in the evolution of PLB’s. The merging of 406 MHz and AIS distress messaging effectively pairs both global and local rescue, thereby maximizing access to the most effective rescue resources available. In addition, NFC capability provides users with the world’s first smartphone connected PLB and the all-new Return Link Service feature provides users with the comfort in knowing that their distress message has been received and their location detected by worldwide Search and Rescue personnel.

  • No Subscription Required
  • 406 MHz Cospas Sarsat Distress Signal (MEOSAR Compatible)
  • 121.5 MHz Local Homing Signal
  • AIS (Automatic Identification System) Locating Signal
  • Smartphone connectivity via NFC (Near Field Communication)
  • Free Ocean Signal Beacon Mobile App (IOS and Android)
  • Return Link Service (RLS) Functionality
  • GNSS via GPS and Galileo Satellites
  • Strobe and Infrared Strobe Light
  • Global Coverage
  • Simple PFD attachment
  • Designed to Integrate with common Inflatable PFDs
  • Multifunction Clip System Included
  • Small and lightweight
  • 5-year battery life
  • Over 24 hours Operational Life

SPECIFICATIONS

406MHz Satellite Transmitter

Frequency 406.031MHz
Tolerance ±1kHz
Output Power 5W Typical
Modulation Phase ±1.1radians
Emission Designator 16K0G1D
Encoding Bi-phase L
Data Rate 400bps

121.5MHz Homing Beacon

Frequency 121.5MHz
Stability ±50ppm
Output Power (PERP) 25 – 100mW
Modulation Swept Tone AM (3K20A3X)
Modulation Factor 0.85-1.0
Modulation Duty Cycle >35%
Duty Cycle 98%

AIS Transmitter

Frequency 161.975/162.025MHz ±500Hz
Transmit Power (EIRP) 1 Watt ±3dB
Baud Rate 9600 baud
Synchronisation UTC
Messages Message 1 (Position), Message 14 (Status)
Repetition Interval 8 messages/min. /Message 14, 2x every 4 minutes

Visible Light Strobe

Light Type High Intensity LED
Light Colour White
Flash Rate 20-30 per minute
Intensity >1 candela

Infra Red Strobe

Light Type IR LED
Light Colour 850nm
Flash Rate 20-30 per minute
Intensity 7.5mW/sr

Battery

Type Lithium/Iron Disulphide (Li/FeS2)
Operating lifetime >24 hours @ -20°C (-4°F)
Lithium Metal Weight (for air transport) <2mg
Replacement Interval 6 years from date of manufacture

GNSS Receiver

Satellite Channels 72 acquisition
Sensitivity -167dBm
Cold Start Re-acquiaition -148dBm
GPS Antenna Microstrip Patch

Environmental

Temperature Range (operational) Class 2 -20°C (-4°F) to +55°C (+131°F)
Temperature Range (storage) Class 2 -30°C (-22°F) to +70°C (+158°F)
Damp Heat (humidity) 40°C (104°F) at 93%
Drop (hard durface) 1m : 6 sides
Water Immersion >10m (1.0bar) : > 60 minutes
Thermal Shock 45°C into 100mm of water : > 1 hour
