Scout VHF fiberglass antenn 0,9m L-kinnitus

Scout VHF fiberglass antenn 0,9m L-kinnitus


The KM-3F antenna is developed especially for sailing boats. It combines lightness and flexibility with an extreme resistance to atmospheric agents. Its elegant style fits perfectly with the boat design. The antenna is supplied together with a stainless steel mounting bracket, that makes the installation quick and stable.
► SO 239 connector
► Mounting bracket supplied with the antenna

Saadavus: Toode on laos Tootekood: KM-3F
Vaata ostukorvi


Technical specifications
 Frequency  156-162 MHz
 Impedance  50 ohm
 Electrical length  1/2 λ
 V.S.W.R.  < 1,5:1
 Polarization  Vertical
 Gain  3 dB
 Max power input  50 W
 DC ground  Yes
 Whip material  Fiberglass
 Connector  SO 239
 Mounting  Stainless steel bracket
 Length  0,9 m
 Weight  0,23 kilo
